Berlin – Click to Enlarge
Acrylic Color Options
Cabinet Color Options
| PRODUCT SPECS | |
| Dimensions | 14′ 9″ × 7′ 8″ × 4′ 9″ |
| Seats | 2 sitting places, swim area |
| Net weight / Water volume | 2 309 lbs / 1 562 gallons |
| Frame | Stainless steel |
| Side cover | HorizontSide™ |
| Reinforcement | Fiberglass reinforced |
| Insulation | Polyfoam (1.4 in/0.4 in) |
| Drains | D50 ball valve |
| POWER REQUIREMENT | |
| 240V 60Hz 62A | |
| MASSAGE SYSTEM | |
| Control box | Gecko ( IN.YE-8) |
| Control panel | SmartTouch (K-1000) |
| Total number of jets | 24 pcs + W-Flow system |
| Laminar fountain jets | 2 x 3 pcs |
| Waterfall | – |
| Heater | 4 kW |
| Pumps (hydro massage) | 1 pc 3 HP single speed + Circ. pump |
| Pumps (swim spa) | 3 pcs 3 HP 2 speed |
| WATER CARE | |
| Cartridge filter | 2 pcs Superfine paper filters |
| Water sanitization | UV-C + Ozone |
| COMFORT SOLUTIONS | |
| LED lights | 21 pcs LED |
| Headrests | 2 pcs |
| sound system | AquaSoul™ Pro 4.1 |
| PREMIUM SOLUTIONS | |
| SmartPhone app – wifi connection | yes |
| Thermo cover | yes (standard 5-3.5 in) |
| Swimming stick | yes |
| Heat exchanger preparation | yes |
